UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8

MPN: 2010 Catalog #: 0078309 Category: Suspension Arms & Components Check Vehicle Fitment

Product Details

Wheel hop or traction issues? We have the solution! Optimize your vehicle's instant center and improve forward traction by lowering the rear of the lower control arm 2, 2-3/4, or 3-1/4. These weld-in brackets are CAD designed to accommodate factory lower control arms as well as all popular aftermarket styles. Robust flanges inside the brackets add reinforcement and ensure factory bushings bolt right in. Brackets installed can provide an average 0.10 second (or better) 60-foot reduction and an overall improvement in launch consistency. Brackets are constructed of 3/16 mild steel and CNC laser cut for precision tolerances.  Relocation brackets are designed to work on both lowered and non-lowered vehicles and feature multiple settings to optimize vehicle handling and traction.

Installation: P/N 2010 weld-in relocation brackets are designed for the factory rear end housings and also fit Strange Engineering brand rear ends. They will not correctly fit Moser Engineering brand rear ends, please see P/N 2011 for a Moser Engineering weld in specific bracket. Installation takes approximately 1-2 hours and requires welding. Brackets are supplied bare metal for welding and include necessary hardware and installation instructions.

UMI Camaro Lower Control Arm Relocation Brackets Weld-In V6, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V6, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V8, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V8, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V8, UMI Performance 82-02 GM F-Body Lower Control Arm Relocation Brackets Weld-In, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V6, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V6, UMI Performance 82-02 GM F-Body Lower Control Arm Relocation Brackets Weld-In

UMI Camaro Lower Control Arm Relocation Brackets Weld-In V6, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V6, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V8, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V8, UMI Camaro Lower Control Arm Relocation Brackets Weld-In V8, UMI Performance 82-02 GM F-Body Lower Control Arm Relocation Brackets Weld-In, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V6, UMI Firebird Lower Control Arm Relocation Brackets Weld-In V6, UMI Performance 82-02 GM F-Body Lower Control Arm Relocation Brackets Weld-In

Reposition your instant center by changing your lower control arm angle for improved traction. Brackets lower the rear of the control arm up to 3, a must for all lowered vehicles to correct lost suspension geometry. By lowering your vehicle, you are changing the lower control arm angle allowing the rear mounting point to sit higher than the front. This will, in return, cause wheel hop and a great deal of traction loss.

Lowered Vehicles: We do not recommend lowering a 3rd or 4th generation F-Body without lower control arm relocation brackets due to the compromise in the geometry on the instant center. Brackets will significantly improve instant center position, eliminate wheel hop and increase traction. Brackets installed will also help 60-foot times of .10 or better, lower ETs and increase track consistency--a must for all lowered vehicles!

Non-Lowered Vehicles: Product installed on a stock height vehicle will also see a great increase in traction by lowering the rearward angle of the lower control arm, allowing more force to be placed on the rear tires. Relocation brackets have two settings to allow the lower control arm to be lowered either 2 or 3, depending on your preference. Settings are placed in a correct pattern that will allow use of all OEM control arms or any aftermarket control arm (brackets do not require a longer control arm.) Brackets installed on a non-lowered F-Body provide a .10 or better 60-foot; reduction and an increase in track consistency.

Installation:Brackets are Weld-in only and install in approximately 1 - 1½ hours. All hardware and installation instructions are included with each kit.

Fits Camaro and Firebird Models.

1982–2002 UMI Performance 82-02 GM F-Body Lower Control Arm Relocation Brackets Weld-In

1982–2002 UMI Firebird Lower Control Arm Relocation Brackets Weld-In V6

1982–2002 UMI Firebird Lower Control Arm Relocation Brackets Weld-In V8

Vehicle Fitment

Please verify year, make, model, and any notes before ordering.

Product Specs

Brand
UMI Performance
Part Number
2010
Catalog Number
0078309
Product Line
Suspension Arms & Components
Category
Suspension
Type
Suspension Arms & Components
UPC / Barcode
2010
Vendor Product Category
Suspension
Vendor Product Subcategory
Suspension Arms & Components
Length
10.00 in
Width
6.00 in
Height
6.00 in
Weight
8.00 lb
Units Per SKU
1
Freight / LTL
No
Air Restricted
No
Prop 65
Y
CARB Approved
Yes
Clearance Item
No
